Chain of Responsibility Pattern in C#: Definition, Use Cases, Pros, Cons, and Examples

The Chain of Responsibility pattern in C# is a behavioral design pattern that passes a request through a chain of handler objects until one of them processes the request.

The Chain of Responsibility pattern allows multiple objects to handle a request without tightly coupling the sender to a specific receiver. In this pattern, each handler decides either to process the request or pass it to the next handler in the chain. This creates a flexible processing pipeline where responsibilities are distributed across multiple classes. The pattern is commonly implemented using abstract handler classes or interfaces that contain a reference to the next handler. In C#, it is widely used in middleware pipelines, event processing systems, validation frameworks, and logging systems.

Why We Use Chain of Responsibility Pattern in C#?

We use the Chain of Responsibility pattern in C# to:

• Reduce tight coupling between request senders and receivers
• Create flexible and extendable processing pipelines
• Allow multiple objects to participate in request handling
• Dynamically add or remove handlers
• Follow the Single Responsibility Principle
• Simplify conditional processing logic
• Improve maintainability in large applications

When Should We Use Chain of Responsibility Pattern in C#?

The Chain of Responsibility pattern should be used when:

• More than one object may handle a request
• The exact handler is unknown beforehand
• Requests need sequential processing
• You want to avoid large if-else or switch statements
• Processing logic should be dynamically configurable
• Different validation or filtering steps are required
• Request processing should be decoupled from business logic

Common Programming Problems Solved by Chain of Responsibility

• Validation pipelines
• Authentication and authorization systems
• Logging frameworks
• Exception handling pipelines
• Request filtering systems
• Event handling systems
• Approval workflows
• Middleware architectures
• Command processing pipelines

Structure of Chain of Responsibility Pattern in C#

Typical participants:

• Client
• Handler Interface / Abstract Handler
• Concrete Handlers
• Request Object

Basic workflow:

• Client sends request to first handler
• Handler processes or forwards request
• Next handler repeats process
• Chain continues until handled or chain ends

Chain of Responsibility Pattern Examples in C#

Example 1: Logger System

Different log levels should be handled by different loggers.

using System;

public abstract class Logger
{
    protected Logger nextLogger;

    public void SetNext(Logger logger)
    {
        nextLogger = logger;
    }

    public void LogMessage(string level, string message)
    {
        if (CanHandle(level))
        {
            Write(message);
        }
        else if (nextLogger != null)
        {
            nextLogger.LogMessage(level, message);
        }
    }

    protected abstract bool CanHandle(string level);
    protected abstract void Write(string message);
}

public class InfoLogger : Logger
{
    protected override bool CanHandle(string level)
    {
        return level == "INFO";
    }

    protected override void Write(string message)
    {
        Console.WriteLine("INFO: " + message);
    }
}

public class ErrorLogger : Logger
{
    protected override bool CanHandle(string level)
    {
        return level == "ERROR";
    }

    protected override void Write(string message)
    {
        Console.WriteLine("ERROR: " + message);
    }
}

public class Program
{
    public static void Main()
    {
        Logger infoLogger = new InfoLogger();
        Logger errorLogger = new ErrorLogger();

        infoLogger.SetNext(errorLogger);

        infoLogger.LogMessage("INFO", "Application started");
        infoLogger.LogMessage("ERROR", "Something failed");
    }
}

Example 2: Authentication Middleware

Requests should pass through authentication and authorization steps.

using System;

public abstract class Middleware
{
    protected Middleware next;

    public void SetNext(Middleware middleware)
    {
        next = middleware;
    }

    public virtual bool Handle(string user)
    {
        if (next != null)
        {
            return next.Handle(user);
        }

        return true;
    }
}

public class AuthenticationMiddleware : Middleware
{
    public override bool Handle(string user)
    {
        if (string.IsNullOrEmpty(user))
        {
            Console.WriteLine("Authentication failed");
            return false;
        }

        Console.WriteLine("Authentication successful");

        return base.Handle(user);
    }
}

public class AuthorizationMiddleware : Middleware
{
    public override bool Handle(string user)
    {
        if (user != "admin")
        {
            Console.WriteLine("Authorization failed");
            return false;
        }

        Console.WriteLine("Authorization successful");

        return base.Handle(user);
    }
}

public class Program
{
    public static void Main()
    {
        Middleware auth = new AuthenticationMiddleware();
        Middleware authorization = new AuthorizationMiddleware();

        auth.SetNext(authorization);

        auth.Handle("admin");
    }
}

Example 3: Expense Approval System

Expense requests should be approved by managers with different approval limits.

using System;

public class ExpenseRequest
{
    public decimal Amount { get; set; }

    public ExpenseRequest(decimal amount)
    {
        Amount = amount;
    }
}

public abstract class Approver
{
    protected Approver nextApprover;

    public void SetNext(Approver approver)
    {
        nextApprover = approver;
    }

    public abstract void Approve(ExpenseRequest request);
}

public class TeamLead : Approver
{
    public override void Approve(ExpenseRequest request)
    {
        if (request.Amount <= 1000)
        {
            Console.WriteLine("TeamLead approved request");
        }
        else if (nextApprover != null)
        {
            nextApprover.Approve(request);
        }
    }
}

public class Manager : Approver
{
    public override void Approve(ExpenseRequest request)
    {
        if (request.Amount <= 5000)
        {
            Console.WriteLine("Manager approved request");
        }
        else if (nextApprover != null)
        {
            nextApprover.Approve(request);
        }
    }
}

public class Director : Approver
{
    public override void Approve(ExpenseRequest request)
    {
        if (request.Amount > 5000)
        {
            Console.WriteLine("Director approved request");
        }
    }
}

public class Program
{
    public static void Main()
    {
        Approver teamLead = new TeamLead();
        Approver manager = new Manager();
        Approver director = new Director();

        teamLead.SetNext(manager);
        manager.SetNext(director);

        teamLead.Approve(new ExpenseRequest(7000));
    }
}

Most Known Real-World Use Cases in C#

• ASP.NET Core middleware pipeline
• Request validation frameworks
• Logging frameworks
• Authentication and authorization systems
• Exception handling pipelines
• Approval workflows
• Event bubbling systems in UI frameworks

Advantages of Chain of Responsibility Pattern in C#

• Reduces coupling between sender and receiver
• Improves code flexibility
• Easier to extend processing steps
• Supports Open/Closed Principle
• Simplifies complex conditional logic
• Enables dynamic handler ordering
• Encourages reusable handler components
• Improves maintainability

Disadvantages (Weak Points) of Chain of Responsibility Pattern in C#

• Request may remain unhandled
• Debugging chains can become difficult
• Long chains may reduce performance
• Handler order can create unexpected behavior
• Increases number of classes
• Runtime configuration may become complex
• Harder to understand for beginners

Comparison with Similar Patterns

Simplified UML-Style Structure
