Memento Pattern in C#: Definition, Examples, Pros, Cons, and Use Cases

The Memento pattern in C# is a behavioral design pattern that captures and restores an object's internal state without exposing its implementation details.

The Memento pattern allows an object to save its current state into a separate snapshot object called a memento. Later, the object can restore itself to that previously saved state when needed. This pattern helps implement undo/redo functionality while preserving encapsulation. The main participants are the Originator (state owner), the Memento (state snapshot), and the Caretaker (state manager). In C#, the Memento pattern is commonly used in editors, games, transaction systems, workflow systems, and history management features.

Why We Use Memento Pattern in C#?

We use the Memento pattern in C# to:

• Save and restore object states
• Implement undo/redo functionality
• Preserve encapsulation
• Track object history
• Roll back failed operations
• Simplify state recovery logic
• Manage snapshots safely
• Reduce direct exposure of internal object data

When Should We Use Memento Pattern in C#?

The Memento pattern should be used when:

• Object states must be restored later
• Undo/redo functionality is required
• State history tracking is needed
• Direct state exposure should be avoided
• Checkpoint systems are required
• Transaction rollback mechanisms are needed
• Complex object states need snapshot support

Common Programming Problems Solved by Memento Pattern

• Undo/redo systems
• Save/load game progress
• Transaction rollback
• Text editor history
• Configuration recovery
• Workflow checkpointing
• State versioning
• Temporary state backups

Structure of Memento Pattern in C#

Typical participants:

• Originator
• Memento
• Caretaker
• Client

Basic workflow:

• Originator creates a snapshot
• Caretaker stores snapshot
• Object state changes
• Caretaker restores snapshot when needed

Momento Pattern Examples in C#

Example 1: Text Editor Undo System

A text editor should support undo functionality.

using System;
using System.Collections.Generic;

public class TextMemento
{
    public string Content { get; }

    public TextMemento(string content)
    {
        Content = content;
    }
}

public class TextEditor
{
    public string Content { get; set; }

    public TextMemento Save()
    {
        return new TextMemento(Content);
    }

    public void Restore(TextMemento memento)
    {
        Content = memento.Content;
    }
}

public class History
{
    private Stack<TextMemento> history = new Stack<TextMemento>();

    public void Save(TextMemento memento)
    {
        history.Push(memento);
    }

    public TextMemento Undo()
    {
        return history.Pop();
    }
}

public class Program
{
    public static void Main()
    {
        TextEditor editor = new TextEditor();
        History history = new History();

        editor.Content = "Version 1";
        history.Save(editor.Save());

        editor.Content = "Version 2";

        Console.WriteLine(editor.Content);

        editor.Restore(history.Undo());

        Console.WriteLine(editor.Content);
    }
}

Example 2: Game Save System

A game should save and restore player progress.

using System;

public class GameMemento
{
    public int Level { get; }
    public int Health { get; }

    public GameMemento(int level, int health)
    {
        Level = level;
        Health = health;
    }
}

public class Game
{
    public int Level { get; set; }
    public int Health { get; set; }

    public GameMemento Save()
    {
        return new GameMemento(Level, Health);
    }

    public void Restore(GameMemento memento)
    {
        Level = memento.Level;
        Health = memento.Health;
    }
}

public class Program
{
    public static void Main()
    {
        Game game = new Game();

        game.Level = 5;
        game.Health = 80;

        GameMemento save = game.Save();

        game.Level = 10;
        game.Health = 20;

        game.Restore(save);

        Console.WriteLine($"Level: {game.Level}");
        Console.WriteLine($"Health: {game.Health}");
    }
}

Example 3: Bank Transaction Rollback

A failed transaction should restore previous account balance.

using System;

public class AccountMemento
{
    public decimal Balance { get; }

    public AccountMemento(decimal balance)
    {
        Balance = balance;
    }
}

public class BankAccount
{
    public decimal Balance { get; private set; }

    public BankAccount(decimal balance)
    {
        Balance = balance;
    }

    public void Deposit(decimal amount)
    {
        Balance += amount;
    }

    public void Withdraw(decimal amount)
    {
        Balance -= amount;
    }

    public AccountMemento Save()
    {
        return new AccountMemento(Balance);
    }

    public void Restore(AccountMemento memento)
    {
        Balance = memento.Balance;
    }
}

public class Program
{
    public static void Main()
    {
        BankAccount account = new BankAccount(1000);

        AccountMemento backup = account.Save();

        account.Withdraw(900);

        Console.WriteLine("Current Balance: " + account.Balance);

        account.Restore(backup);

        Console.WriteLine("Restored Balance: " + account.Balance);
    }
}

Most Known Real-World Use Cases in C#

• Text editor undo/redo systems
• Game save/load systems
• Database transaction rollback
• Drawing applications
• Workflow recovery systems
• IDE history management
• Form state recovery
• Snapshot/version management

Advantages of Memento Pattern in C#

• Preserves encapsulation
• Simplifies undo/redo implementation
• Enables state restoration
• Supports rollback operations
• Keeps state snapshots isolated
• Improves recovery mechanisms
• Reduces direct state manipulation
• Makes history tracking easier

Disadvantages (Weak Points) of Memento Pattern in C#

• Can consume large memory for many snapshots
• Snapshot management may become complex
• Large objects increase storage costs
• Caretaker can grow significantly
• Performance overhead in frequent saves
• Difficult with deeply nested object graphs
• May require cloning complex structures

Comparison with Similar Patterns

Simplified UML-Style Structure
