Mediator Pattern in C#: Definition, Examples, Pros, Cons, and Use Cases

The Mediator pattern in C# is a behavioral design pattern that centralizes communication between objects by introducing a mediator object that coordinates their interactions.

The Mediator pattern reduces direct dependencies between objects by making them communicate through a mediator instead of referencing each other directly. This helps create loosely coupled systems where object interactions are centralized and easier to manage. Each participating object, called a colleague, sends requests to the mediator, and the mediator coordinates communication between colleagues. The mediator encapsulates interaction logic, reducing complex object relationships and improving maintainability. In C#, the Mediator pattern is commonly used in UI frameworks, messaging systems, chat applications, CQRS architectures, and workflow coordination systems.

Why We Use Mediator Pattern in C#?

We use the Mediator pattern in C# to:

• Reduce tight coupling between objects
• Centralize communication logic
• Simplify object collaboration
• Improve maintainability
• Prevent complex object dependency graphs
• Support cleaner architecture
• Simplify component reuse
• Manage communication workflows efficiently

When Should We Use Mediator Pattern in C#?

The Mediator pattern should be used when:

• Many objects communicate with each other
• Object dependencies become difficult to manage
• Communication logic is complex
• Components should remain loosely coupled
• Reusable independent components are needed
• Centralized coordination is preferred
• UI components interact heavily

Common Programming Problems Solved by Mediator Pattern

• UI component communication
• Chat room systems
• Workflow coordination
• Event orchestration
• CQRS request handling
• Air traffic control systems
• Smart home coordination
• Messaging systems
• Notification hubs

Structure of Mediator Pattern in C#

Typical participants:

• Mediator Interface
• Concrete Mediator
• Colleague Classes
• Client

Basic workflow:

• Colleague sends message to mediator
• Mediator receives request
• Mediator decides target recipients
• Mediator coordinates communication

Mediator Pattern Examples in C#

Example 1: Chat Room System

Users in a chat room should communicate without directly referencing each other.

using System;
using System.Collections.Generic;

public interface IChatMediator
{
    void SendMessage(string message, User user);
    void AddUser(User user);
}

public class ChatMediator : IChatMediator
{
    private List<User> users = new List<User>();

    public void AddUser(User user)
    {
        users.Add(user);
    }

    public void SendMessage(string message, User sender)
    {
        foreach (var user in users)
        {
            if (user != sender)
            {
                user.Receive(message);
            }
        }
    }
}

public class User
{
    private IChatMediator mediator;

    public string Name { get; }

    public User(IChatMediator mediator, string name)
    {
        this.mediator = mediator;
        Name = name;
    }

    public void Send(string message)
    {
        Console.WriteLine($"{Name} sends: {message}");
        mediator.SendMessage(message, this);
    }

    public void Receive(string message)
    {
        Console.WriteLine($"{Name} receives: {message}");
    }
}

public class Program
{
    public static void Main()
    {
        IChatMediator mediator = new ChatMediator();

        User john = new User(mediator, "John");
        User alice = new User(mediator, "Alice");

        mediator.AddUser(john);
        mediator.AddUser(alice);

        john.Send("Hello Alice");
    }
}

Example 2: Air Traffic Control System

Aircraft should communicate through a control tower instead of directly with each other.

using System;

public interface IControlTower
{
    void SendMessage(string message, Aircraft aircraft);
}

public class ControlTower : IControlTower
{
    public void SendMessage(string message, Aircraft sender)
    {
        Console.WriteLine($"Tower relays from {sender.Name}: {message}");
    }
}

public class Aircraft
{
    private IControlTower tower;

    public string Name { get; }

    public Aircraft(IControlTower tower, string name)
    {
        this.tower = tower;
        Name = name;
    }

    public void Send(string message)
    {
        tower.SendMessage(message, this);
    }
}

public class Program
{
    public static void Main()
    {
        IControlTower tower = new ControlTower();

        Aircraft plane1 = new Aircraft(tower, "Flight A1");
        Aircraft plane2 = new Aircraft(tower, "Flight B2");

        plane1.Send("Requesting landing permission");
        plane2.Send("Ready for takeoff");
    }
}

Example 3: Smart Home Coordination

Smart home devices should coordinate actions through a central hub.

using System;

public interface ISmartHomeMediator
{
    void Notify(string eventName, Device sender);
}

public class SmartHomeHub : ISmartHomeMediator
{
    public void Notify(string eventName, Device sender)
    {
        if (eventName == "MotionDetected")
        {
            Console.WriteLine("Hub turns on hallway lights");
        }
    }
}

public abstract class Device
{
    protected ISmartHomeMediator mediator;

    public Device(ISmartHomeMediator mediator)
    {
        this.mediator = mediator;
    }
}

public class MotionSensor : Device
{
    public MotionSensor(ISmartHomeMediator mediator) : base(mediator)
    {
    }

    public void DetectMotion()
    {
        Console.WriteLine("Motion detected");
        mediator.Notify("MotionDetected", this);
    }
}

public class Program
{
    public static void Main()
    {
        ISmartHomeMediator hub = new SmartHomeHub();

        MotionSensor sensor = new MotionSensor(hub);

        sensor.DetectMotion();
    }
}

Most Known Real-World Use Cases in C#

• ASP.NET CQRS mediator libraries
• Chat applications
• UI dialog coordination
• Workflow orchestration
• Event aggregation systems
• Air traffic control systems
• Smart home automation
• Multiplayer game communication
• Enterprise messaging systems

Advantages of Mediator Pattern in C#

• Reduces object coupling
• Simplifies communication logic
• Centralizes interaction management
• Improves maintainability
• Enhances component reusability
• Reduces dependency complexity
• Makes systems easier to extend
• Improves code readability

Disadvantages (Weak Points) of Mediator Pattern in C#

• Mediator can become overly complex
• Centralized logic may create bottlenecks
• Large mediators may violate Single Responsibility Principle
• Adds extra abstraction layer
• Debugging communication flow can become harder
• Too many colleagues may overload mediator
• Can evolve into a “god object”

Comparison with Similar Patterns

Simplified UML-Style Structure
